Magnetic Door Switch RC-33 NC Recessed Wired Security Window Door Contact Sensor Alarm White 10 Pair

Set up Directions

1. Drill set up gap with a diameter of 10 mm.

2. The door and window magnet needs to be put in on the closed place of the door/window/drawer.

3. The magnet half is put in within the movable door and window. The change half is put in within the fastened door and window body. The change half and the magnet half needs to be aligned as a lot as potential.

4. The door magnet needs to be away from the sturdy magnetic area interference supply resembling a transformer. In any other case, the working traits of the door magnet might be modified and potential mistaken actions.

5. The door magnetic change is a glass-encapsulated change. When putting in, watch out to not use an excessive amount of drive or savage set up, which is straightforward to break. If the voltage and present are too massive, the change will even be broken.

Notice

1. The Magnetic Door Change should be put in in response to the sensing distance;

2. It might probably solely present a change sign to the gadget, which can not immediately load the ability, nor immediately join the lamp! About Usually Closed and Usually Open

N.C

NC means Usually Closed: When the magnet collectively, the circuit is conductive( gentle on ); when the magnet separates, the circuit is just not conductive ( gentle off ). When make order, pls test rigorously!

Bundle Dimensions ‏ : ‎ 4.13 x 2.44 x 0.87 inches; 2.12 ounces
Merchandise mannequin quantity ‏ : ‎ RC-33
Date First Out there ‏ : ‎ March 15, 2022
Producer ‏ : ‎ Manesi
ASIN ‏ : ‎ B09VKXGHHS
Nation of Origin ‏ : ‎ China

Product Title: Magnetic Door Change Mannequin: RC-33
Contact Kind: NC (Usually Closed) Actuation Distance: 18mm ± 5mm Max. Present: 0.5A
Max. Contact Energy: 10W Working Voltage: DC0-100V
Every Measurement(Approx): 17 x 10.6mm / 0.67 x 0.42-inch (H*D) Cable Size(Every): 25cm / 9.8-inch Materials: ABS (Housing) Wire Kind: 1007UL#24AWG
Shade: White Web Weight: 80g Bundle Content material: 10pcs x Magnetic Door Change
