UHPPOTE Normal Closed Wired Screw-Terminal Surface-Mount Magnetic Contact for Window Door Security (Pack of 5)

Product Description

Description:

Miniature surface-mount magnetic contacts.Gold-plated screw terminals for longer life and reliability.Contact reed change is SPST, iridium-plated to have a excessive melting level and Vickers hardness, for greater dealing with energy and longer life.Mounting screws and double-sided tape included.Nice to be used in household and manufacturing unit window, door. and so on.NORMALLY CLOSED: When the magnet collectively, the circuit is conductive (mild on); When the magnet separate, the circuit is just not conductive (mild off).

Options:

Mounting Tabs: Sure / removableMaterial – Case: Excessive-impact ABS plasticContacts: Iridium-platingSwitch Dimensions: 2-1/64″x25/64″x9/32″ (51x10x7mm)Magnet Dimensions: 2-1/64″x25/64″x9/32″ (51x10x7mm)Dry Contact Output: NC (Regular closed)Contact Ranking: 10W/100VDC/0.5A in MAX

Working Temperature: -15°~160°F (-25°~70°C)Swap Cycles: 50 Million (0.1mA@5VDC)Magnet Sort: Uncommon-earth neodymiumColor: WhiteHousing Materials: PlasticRecommend cable: 1007UL #24AWGProduct: 0.32oz (9g)

Bundle Together with: 5 x Wired contacts

About Usually Closed and Usually Open

NC means Usually Closed: When the magnet collectively, the circuit is conductive (mild on); when the magnet separates, the circuit is just not conductive (mild off).

Swap Sort: NC (Regular closed kind)
This Contact Works with Any Entry Management or Burglar Alarm System Out there
This contact cannot join on to energy, it really works together with your alarm system present a change sign. Working present underneath 12V
Nice to be used in household and manufacturing unit window, door. and so on.
NC means Usually Closed: When the magnet collectively, the circuit is conductive (mild on); When the magnet separate, the circuit is just not conductive (mild off).
